- Lowers air temperature by up to 20°F. Adjustable thermostat.
- Two flexible air chutes blow cold air up to 5 feet away.
- 3.5-gallon condensate tank with overflow protection.
- Automatic restart after a power failure. 8' power cord.
- 4" rubber casters: 2 swivel with brake, 2 rigid.
-
DIMENSIONS:
- Actual: 16 3/4 x 37 3/4 x 26 1/8" (W x H x D)
- Air Chutes: 5 x 16" (Diam x L)
- Casters (Width): 1 1/8"
FEATURES:
- Fan Type: Direct drive
- Auto shut-off motor and compressor for overload protection.
- Condensate Tank:
- Includes float switch and alarm to prevent overflow.
- Tank fills up based on humidity of the space.
- On average, should be emptied every 8-12 hours.
- Cooling Capacity: 1.5 Ton
- One ton is equal to amount of heat required (12,000 BTU) to melt one ton of ice in a 24 hr period.
- 1.5 Ton= 16,800 BTU and will cool a 600 sq ft room with 9' ceilings.
USAGE:
- Uses standard 12 x 12 x 1" air filter.
- Standard Office Environment: Replace every 3 months.
- Water should be emptied prior to end-of-season storage.
SPECIFICATIONS:
- 14.5 amps
- Cord: 12 gauge, NEMA 5-20
- Refrigerant: R410A
- CFM:
- Evaporator (Cold Side): 625
- Condenser (Hot Side): 825
REPLACEMENT CASTERS:
- 4" Thermoplastic Rubber:
- Locking Swivel: H-8776
- Rigid: H-8775
|
