ROTHENBERGER Portable Pipe Threading Machine: Supertronic 2SE, For 1/2 in to 2 in Pipe, 1 hp, Std
Item 60PZ78
Mfr. Model 63004
Portable pipe threading machines are more compact than stationary threaders and light enough to transport to jobsites. These corded machines allow long run times for repetitive threading tasks, maintain full power during operation, and have no batteries to recharge.
Item 60PZ78
Mfr. Model 63004
Brand
ROTHENBERGER
ROTHENBERGER
Max. Pipe Dia.
2 in
2 in
Min. Pipe Dia.1/2 in
Phase
Single-Phase
Single-Phase
Horsepower
1 hp
1 hp
Chuck Type
Manual
Manual
Includes
1 gal Oil; Foot-Operated Safety Switch; Reamer
1 gal Oil; Foot-Operated Safety Switch; Reamer
No. of Speeds
1
1
Free Speed
40 RPM
40 RPM
Motor Type
Standard
Standard
Through-the-Head Oiling
Yes
Yes
Thread Type
NPT
NPT
Max. Bolt Size
4 in
4 in
Min. Bolt Size
1/2 in
1/2 in
Die Head Sizes
1/2 in to 3/4 in
1/2 in to 3/4 in
No. of Die Heads
0
0
Tool Series
Supertronic 2SE
Supertronic 2SE
Tool Weight
151 lb
151 lb
Frequency
60 Hz
60 Hz
Kit Contents
Bare Tool
Bare Tool
Machine Type
Stationary Power Threading Machine
Stationary Power Threading Machine
Mount Type
Stand
Stand
Oil Capacity
0.5 gal
0.5 gal
Overall Width
14.5 in
14.5 in
Power Output
1,150 W
1,150 W
Power Source
Corded
Corded
Pump Type
Automatic Oil Feed
Automatic Oil Feed
Reversible
Yes
Yes
Switch Type
Integral On/Off Foot Switch
Integral On/Off Foot Switch
Threading Equipment Included
Reamer
Reamer
Manufacturer Part Number
63004
63004
Voltage
120 V
120 V
UNSPSC
23171708
23171708
Country of Origin
Japan (subject to change)
Japan (subject to change)
