Centrifugal Roof Supply Fan: 15 1/2 in Wheel, 3,447 cfm, 1/2 in wc Max., ODP, 1/2 hp, 1 Ph, Roof

  • Sale
  • $3,822.00


Centrifugal Roof Supply Fan: 15 1/2 in Wheel, 3,447 cfm, 1/2 in wc Max., ODP, 1/2 hp, 1 Ph, Roof

Brand
DAYTON
Drive Type
Belt Drive
Includes Drive Package with Motor
Yes
Assembly
Unassembled
Wheel Diameter
15-1/2 in
Supply Airflow @ 0.000 in SP
3,447 cfm
Maximum Static Pressure
1/2 in wc
Maximum Inlet Air Temperature
120 °F
Nameplate Voltage
115/208-230V AC
Phase
1
Motor Enclosure
Open Dripp roof
Motor Horsepower
1/2 hp
Brake Horsepower
27/50 hp
Motor Speed
1,725 RPM
Maximum Fan Speed
535 RPM
Frequency
60 Hz
Current
7.6/3.7 to 3.8 A
Speed Controllable
No
Number of Speeds
1
Bearing Type
Sealed Pillow Block
Mount Type
Roof Curb
Mounting Location
Roof
Wheel Type
Forward Curved
Wheel Material
Steel
Filter Material
Aluminum
Number of Filters
2
Filter Area
3-3/4 sq ft
Filter Housing Height
27-1/2 in
Filter Housing Width
28-1/8 in
Filter Housing Depth
29-1/4 in
Housing Material
Steel
Base Shape
Square
Base Height
1.5 in
Base Width
34-1/2 in
Base Length
34-1/2 in
Overall Height
32 in
Overall Length
34-1/2 in
Overall Width
63-3/4 in
Includes
Drive Package; Washable Aluminum Filters
Application
Commercial Kitchen; Institutional Buildings
Spark Resistant Construction Type
A
Standards
AMCA Sound and Air; UL/cUL 705
Compatible Curb Grainger Part Number
2RB80; 2ZV84; 3C438; 4C455; 4HX42; 4HX50
Housing Finish
Galvanized
Features
Air Handling Quality Bearings Meet Minimum of L10-100000 Hours; Neoprene Isolators Minimize Vibration and Noise
UNSPSC
40101501
Country of Origin
Varies (subject to change)

Product Description

Belt-drive filtered supply fans provide filtered supply air to indoor commercial spaces. These fans come with a drive package that includes a motor, sheaves, belts, and bushings. They feature washable aluminum filters and a weather hood that makes maintenance simple and fast. Belt-drive fans are typically quieter and provide more control over the fans' blade speed and airflow than direct-drive fans.


Item 7D505
Mfr. Model 7D505
