Actuator: Damper, Floating Point/On/Off, Non-Spring Return, 35 in-lb, 24V AC, Screw Terminals
- Item
- 41P473
- Mfr. Model
- M9104-IGA-3S
-
Non-fail-safe actuators have no fail-safe mechanism to provide movement during power outages. This makes them more compact and easier to maintain than fail-safe actuators. They open and close valves and dampers for non-critical components and infrastructure.
- Manufacturer Part Number
- M9104-IGA-3S
- Brand
- JOHNSON CONTROLS
- Product Type
- Actuator
- Application
- Damper
- Spring Return
- Non-Spring Return
- Signal Type
- On/Off; Floating Point
- Rated Torque
- 35 in-lb
- Input Voltage
- 24V AC
- Power Consumption
- 3 VA
- Time to Close
- 30 sec
- Electrical Connection Type
- Screw Terminals
- For Use With Building Automation Systems
- Building Automation System Compatible
- NEMA Rating
- 1
- IP Rating
- IP40
- Mounting Type
- Direct Mount
- Maximum Operating Temperature
- 140 °F
- Minimum Operating Temperature
- -4 °F
- Includes
- Anti-Rotation Bracket
- Shaft Rotation
- CW/CCW
- Stroke Degree
- 93°
- For Shaft Shape
- Round; Square
- For Shaft Diameter
- 1/2 in
- For Shaft Height
- 3/8 in
- For Shaft Width
- 3/8 in
- Overall Height
- 5-1/8 in
- Overall Width
- 2-7/8 in
- Overall Depth
- 2-3/4 in
- Standards
- C-Tick Mark Australia; CE Certified; CSA Certified C22.2 No. 139; EMC Directive 2004/108/EC; Guide No. XAPX for USA and Canada; NZ Emissions Compliant; UL Listed 60730-1; UL Listed E4436
- Number of Auxiliary Switches
- 0
- Auxiliary Switch Included
- No
- UNSPSC
- 31251501
- Country of Origin
- Mexico
