PROTECT AIR Miniature Regulator: 1/4 in Female NPT, 1/4 in Male NPT, Brass, 159 psi Max Op Pressure
inlet Connection
1/4 in Female NPT
1/4 in Female NPT
Outlet Connection
1/4 in Male NPT
1/4 in Male NPT
Maximum Operating Pressure
159 psi
159 psi
Maximum Pilot Adjustment
43.7 psi
43.7 psi
Tolerance
+0/-4.5 psig
+0/-4.5 psig
Body Material
Brass
Brass
Seal Material
Buna-N
Buna-N
Operating Temperature
-4 °F to 140 °F
-4 °F to 140 °F
Pipe Size
1/4 in
1/4 in
Standards
OSHA 1910.242/1917.154; OSHA 1910.95; OSHA 1926.302
OSHA 1910.242/1917.154; OSHA 1910.95; OSHA 1926.302
ApplicationCommercial Use; Industrial Use; Institutional Use; Light Commercial Use; Residential Use
Manufacturer Part Number
PCR233FS1229
PCR233FS1229
For Media
Air
Air
Inlet Connection Gender
Female
Female
Inlet Connection Size
1/4 in
1/4 in
Inlet Connection Type
NPT
NPT
Operating Temperature - Maximum
140 °F
140 °F
Operating Temperature - Minimum
-4 °F
-4 °F
Outlet Connection Gender
Male
Male
Outlet Connection Size
1/4 in
1/4 in
Overall Height
9/16 in
9/16 in
Overall Width
1-1/2 in
1-1/2 in
Outlet Connection Type
NPT
NPT
Country of Origin
Switzerland
Switzerland
Pressure regulators are threaded onto pneumatic blow guns to supply preset, constant pressure to optimize tool efficiency and reduce compressed air waste. They are nonadjustable and tamperproof to protect personnel and machinery.
Item 808FF8
Mfr. Model PCR233FS1229
